全系列1206贴片电容 10% X7R 1000pF 1200V陶瓷贴片电容

信昌全系列陶瓷电容/贴片电容

Specification：
1)High Voltage : 100V ~10KV
2)High Capacitance : Max 330uF
3)Mid-Voltage and High Cap : 50V to 250V 1uF up
4)High Precision : tolerance by ±2% / ±1%
5)Safety recognized : X1/Y2 , X2 , 1808 to 2211
6)Big size : 3035 / 4252 / 5550 / 5780 / 6560/ 7680/ 8850/ 13060
7)Low ESR : 0805 to 2220
8)Anti-Bending : (Soft termination) : 0603 to 2225

MLCC PRODUCTS

Portfolios	Series	Size	Dielectric	Rating Volt	Capacitance
General Purpose	FN Series	0402 to 1812	NPO/X7R X5R/Y5V	≦50V	≦0.82uF
High Cap Mini-Volt.	FS Series	0402 to 1812	X7R/X5R Y5V	≦50V	1uF to 300uF
High Cap Mid-Volt.	FS Series	1206 to 2225	X7R	50V to 100V	0.68uF-10uF
Middle Voltage	FM Series	0603 to 2225	NPO/X7R	≧100V to 630V	≦820nF
High Voltage	FV Series	1808/2211/2220	NPO/X7R	≧1000V	≦150nF
Safety Certificated	FH & FK Series	1206 to 2211	NPO/X7R	AC 250V	≦5.6nF
High Freq.	RF & HH Series	0201 to 0805	NPO	6.3V to 630V	≦3.3nF
Big Size (Customize)	FG Series	>2220	NPO/X7R	25 to 10000V	Full range
Low D.F.	FL Series	0805 to 2220	X7R	100V/250V/500V	≦1.2uF
Soft Terminal MLCC	FP Series	0805 up	X7R	≧100V to 3000V	Full range


Application
1)Communication ( Modem, Cable Modem, LAN, HUB, Router, ADSL, VDSL, Cell Phone, WLAN, Splitter )
2)Consumer Electronics ( Digital Camera, PS3,X-Box )
3)Industrial Electronics ( Connector, Instrument )
4)Power ( DC-AC Inverter, SPS, Adapter, Charger, DC-DC Converter, Battery Pack for N/B & Cell Phone, Ballast )
